Specifications
Contact Current Rating 15 A
Current Rating 15 A
Differential Travel 508 µm
Electrical Life 500000 cycles
Max Current Rating 15 A
Max Operating Temperature 80 °C
Max Voltage Rating (AC) 500 V
Max Voltage Rating (DC) 250 V
Min Operating Temperature -25 °C
Number of Poles 1
Number of Positions 2
Operating Force 1.57 N
Operating Position 30.1752 mm
Orientation Straight
Overtravel 2.3876 mm
Packaging Bulk
Switch Function On-Mom
Termination Screw
Throw Configuration SPDT
Voltage Rating (AC) 250 V
Voltage Rating (DC) 30 V
