Specifications
| Expanded Inner Diameter | 1.0 mm (approx. 0.039") |
| Recovered Inner Diameter | 0.5 mm to 0.65 mm max. |
| Wall Thickness (Recovered) | Approx. 0.18 mm to 0.22 mm |
| Material | Cross-linked polyolefin |
| Shrink Ratio | 2:1 (shrinks to 1/2 of original diameter) |
| Operating Temperature | -55°C to +125°C or +135°C |
| Minimum Shrink Temp. | +70°C (Full recovery at +110°C to +125°C max) |
| Voltage Rating | Typically 600V (some up to 15 kV/mm dielectric strength) |
| Flammability | Flame retardant, VW-1 (self-extinguishing) |
| Length | 200 meters |
