Specifications
Key Specifications
- Model: HS-500-12 / S-500-12
- Output Voltage: 12V DC (Adjustable, typically ±10% or 11V–13V)
- Output Current: 0-40A
- Rated Power: 500W (Note: Some models are rated 480W)
- Input Voltage: 90-132VAC / 180-264VAC (Switch selectable)
- Efficiency: ~83% - 85%
- Dimensions: Approximately 215/238 x 115/124 x 50/65 mm
- Weight: Approximately 0.95 kg - 1.35 kg
Features & Protections
- Cooling: Built-in DC fan (Automatic on/off)
- Protections: Short circuit, Overload, Overvoltage, and Over-temperature
- Indicator: LED indicator for power on
- Terminal Strip: Screw terminal block for output connections
- Safety Standards: CE, RoHS, ISO9000
