Technical Details
Type - NPN
Collector-Emitter Voltage: 300 V
Collector-Base Voltage: 300 V
Emitter-Base Voltage: 5 V
Weight: 1.5 g
Collector Current: 0.1 A
Collector Dissipation - 7 W
DC Current Gain (hfe) - 40 to 320
Transition Frequency - 70 MHz
Operating and Storage Junction Temperature Range -55 to +150 °C
Package - TO-126
Classification of hFE
The 2SC3417 transistor might have a current gain anywhere between 40 and 320. The gain of the 2SC3417-C will be in the range from 40 to 80, 2SC3417-D ranges from 60 to 120, 2SC3417-E ranges from 100 to 200, 2SC3417-F ranges from 160 to 320.
Marking
Sometimes the "2S" prefix is not marked on the package - the 2SC3417 transistor might be marked "C3417".
Complementary PNP transistor
The complementary PNP transistor to the 2SC3417 is the 2SA1353.
SMD Equivalent
The SMD version of the 2SC3417 is available as the PMBTA42 (SOT-23).
