Product name: Cermet Potentiometer
Model:Â 3326W-102
Withstand Voltage: 700V
Rated power: 1/2 W
Resistance value: 1K Ohm
Tolerance: +/-10 percentÂ
Terminal number: 3
Number of turn: 1
Adjustment Type: top adjustment
Mounting Type:Â Through hole(dip)
Resistive Material: Cermet
Dimension: 6. 8 x 6. 8mm/ 1/4" x 1/4" (low)
Length: 11mm/ 7/16"
Lead distance: 4 mm / 5/32"5mm / 1/5"
Color: Blue
Weight: 2G
Description
-
A common element in electronic devices is a three-terminal resistor with a continuously adjustable tapping point controlled by rotation of a shaft or knob.
-
Cermet resistive material trimming potentiometer for device interior or printed circuit boards which adjustable the resistance less.
-
Through hole dip mounting Type.
-
One turn design cermet potentiometer, square linear
