Specifications
Type: Ethernet Cable
Length: 305m
Standard: CAT5e, Shielded
Ethernet Support: 10/100/1000 MBit
Conductor Wire Gauge: 24 AWG
Conductor: Solid bare copper
Conductor Diameter: 0.50 +- 0.005 mm
Insulation Type: Solid PE
Insulation Thickness: 0.295mm, nominal
Insulation Diameter: 1.16 +- 0.02 mm
Separation: Polyester Wrapping
Thick: 0.025mm
Extent: 20 mm
Anti-Crosstalk: LDPE: 4.2 x 0.3 mm
Cable Shield: Aluminum Foil
Thick: 0.060 mm
Extent: 20 mm
ESD Drain Wire: 0.4 TC
Rip Cord: Yes
Jacket Material: PE
Jacket Thickness: 0.52mm, nominal
Jacket Outer Diameter: 6.8 +- 0.30 mm
Jacket Color: Black
Reference Standard: ISO/IEC 11801, TIA/EIA568B.2
