Description
Specifications
| Model | FCS-500 |
|---|---|
| General | |
| Scan Rate | 360 scan/sec |
| Scanner Type | 1500 Pixel CCD |
| Maximum Pitch | - |
| Minimum Skew | - |
| Depth of Field | 20~ 95 mm (CODE 39, 16mil, PCS90%) |
| Contrast Ratio | 45% |
| Scan Patten | Single scan line (trigger/continuous) |
| Resolution | 0.1mm (4 mil) max |
| System Interface | Keyboard Wedge / RS-232 / USB |
| Readable Bar Code Symbologies | Code 39 / 32, Full ASCII Code 39, Code 128, Code 11, Interleaved 2 / 5, Industrial 2 / 5 / IATA, Matrix 2 / 5, China, Postage, Code93, MSI / PLESSEY, Codabar / NW7, EAN-8 / JAN-13, UPC-A, EAN-13 / JAN-13, ISBN / ISSN, RSS-14 (Truncated & Limited & Stacked) |
| Electrical | |
| Power Input | 5VDC ± 5% |
| Others | |
| Material | ABS |
| Color | Black |
| Shock Resistance | 1m drop onto concrete |
| Compliance | CE, FCC |
| Laser Class | - |
| Weight | 65 g (with cable) |
| Dimension (W x H x L: mm) | 50 x 18.2 x 36.58 |
| Cable Length | 1.8 m |
| Ambient Light | 4500 lux (fluorescent) |
| Operating Temperature | 0°C ~ 45°C |
| Operating Humidity | - |
| Storage Temperature | -20°C ~ 60°C |
| Storage Humidity | 20% - 85% RH, non-condensing |
