Specifications
Accurate temperature control
- Microprocessor temperature controlled
- Temperature calibration function
- Closed-circuit sensor design
Certified international safety standard
- Complies with CE and ESD standards, conform to RoHS.
- Comes with AWGÂ 18 (0.823mm2) UL Certified Wires.
- Silicone handpiece cord wire heat-resistant up to 200oC
- Additional ground contact and power cord socket.
High Power, Fast Warm-Up & Energy Saving
- Alumina Ceramic Soldering iron heating element features high power, fast warm-up.
- The individual function starts to save energy, or share function by 2 users at the same time.
- Adjustable temperature and airflow for easy surface or hole mount components QFP, SOP type IC devices rework.
Interchangeable and applicable to most branded hot air nozzles and tips
- 3 nozzles included with this rework station.
- Interchangeable hot air nozzles design for different types of surface mount components.
- Also applicable to most branded heating elements and nozzles.
Auto Cool-Off Process to prolong the service lifetime
After the power switch is turned off, the auto cool-off process leaves the blower on until the nozzle is cool.
| Specification | SS-989E | SS-989E7 | SS-989B | SS-989H |
| Power Consumption | 700W | |||
| Soldering Power | 60W | |||
| Soldering Iron Temperature Range | 200ËšC ~ 480ËšC (392ËšF ~ 896ËšF) | |||
| Hot Air Temperature Range | Room temperature ~ 480ËšC ( 896ËšF) | |||
| Soldering Iron Heating Element | Alumina Ceramic | |||
| Hot Air Heating Element | Metal Heating Core | |||
| Pump/Motor Type | Diaphragm Pump | |||
| Air Capacity | 24L/min (max) | |||
| Equipment noise | 45dB | |||
| Temperature Display | LED | |||
| Power Input |
AC 110V~120V 60Hz |
AC 127V 60Hz |
AC 220V~240V 50Hz |
AC220V~240V 50Hz |
| Standard Plug |  |
|
 |
 |
| Dimensions | 255(L)x190(W)x140(H)mm | |||
| Weight | 4200 g (w/ hot air gun) | |||
| Accessories |
Hot Air Gun |
Hot Air Gun |
Hot Air Gun |
Hot Air Gun |
| Soldering Iron (AC 24V/60W) 9SS-900N-SI x 1pcs, Soldering Stand x 1pcs, Nozzle 9SS-900-A1 (Ø2.3mm) x 1pcs, Nozzle 9SS-900-A2 (Ø6.4mm) x 1pcs, Nozzle 9SS-900-A3 (Ø8.8mm) x 1pcs | ||||
