Specifications
Brand
|
SAMSUNG |
Model |
ATNA56WR14-0 |
Diagonal Size |
15.6 inch |
Type |
AM-OLED , OLED
|
Pixel Format |
3840(RGB)×2160, UHD, 283PPI
|
Configuration |
RGB Vertical Stripe
|
Active Area |
344.218(W)×193.622(H) mm |
Outline Dim. |
/ |
Bezel Area |
348.218(W)×215.662(H) ×2.9(D) mm |
Treatment |
Glare (Haze 0%) |
Luminance |
440 cd/m² (Typ.) |
Contrast Ratio |
100000:1 (Typ.) (TM) |
View Direction |
Symmetry |
Response Time |
1 (Typ.)(Tr+Tf) |
Viewing Angle |
85/85/85/85 (Typ.)(CR≥10)
|
Operating Mode |
/ |
Support Color |
1.06B 100% DCI-P3 |
Light Source |
self |
Form Style |
/ |
Designed For |
/ |
Frame Rate |
60Hz |
Touch Panel |
Without
|
Interface Type |
eDP ，40 pins Connector
|
||
Power Supply |
3.3V (Typ.)
|
||
Environment |
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -40 ~ 85 °C |
