Description
Specifications
Connector type : sma connector
Working Voltage : 335V max
Frequency Range : DC~12.4GHz
Vswr : Max 1.2
Impedance : 50 Ω
Temp.range : -55~+155°C
Conductor resistance : Internal ≤ 3mΩ, External ≤ 2mΩ
Material : Shell : brass, gold plated, Nut : brass, gold plated, Pin : brass,gold plating
Insulating resistance : ≥ 5000 MΩ
Withstanding voltage : 5000V rms
Usability : 500 Cycles min
